KING TONY 433016S 1/2-inch Drive 12-Point Standard Socket, 1/2-inch

Brand: KING TONY
Manufacturer model number: 433016S
Order code: Y8E8W5R
MOQ: 1 顆
Supply status: In Stock
Selected configuration: Standard item

$140.00/ 顆~~Was $200.00~~-30%

Payment Options: FPSFlexible PaymentBank Transfer
Buyer Protection: Genuine ProductsCompany InvoiceAfter-sales Service

Sold by

JACO自營旗艦店

自營

The KING TONY 433016S is a standard-length 12-point inch hand socket with a 1/2-inch square drive and a 1/2-inch opening. Its 38 mm overall length suits manual fastener work using a matching-drive ratchet or extension. This listing is for one socket.

KING TONY standard 12-point inch socket representative image marked 1 inch; 433016S is 1/2-inch drive, 1/2-inch opening, sold individually — Representative KING TONY 1/2-inch-drive, 12-point inch standard socket image. The pictured tool is visibly marked 1 inch; it is not an exact photograph of this 1/2-inch opening size. This listing is model 433016S, with a 1/2-inch square drive, 1/2-inch opening and 38 mm overall length, sold as one socket. The image does not establish interchangeability with other model codes.

12-point opening and manual square drive

12-point working end for 1/2-inch fasteners.
Chrome-vanadium alloy steel with a polished, chrome-plated finish.
Four ball-retaining grooves for the detent ball on a manual drive tool.
Inch specification according to ANSI/ASME B107.1.

This is a standard-length hand socket, not a deep or impact socket. Check the square-drive size separately from the fastener opening: both are 1/2 inch on model 433016S.

Specifications

Brand	KING TONY
Model	433016S
Type	Standard-length 12-point inch hand socket
Square drive	1/2 inch (12.7 mm)
Opening	1/2 inch
Overall length L	38 mm
Working-end outside diameter D1	19.0 mm
Drive-end outside diameter D2	23.3 mm
Working-end depth ℓ	10.0 mm
Weight	62 g (manufacturer 2022 catalogue data)
Material	Chrome-vanadium alloy steel (Cr-V)
Finish	Polished, chrome-plated
Retention	Four ball-retaining grooves
Standard	ANSI/ASME B107.1
Price unit	顆 — one socket

What's in the Box

433016S 1/2-inch-drive, 1/2-inch-opening standard 12-point inch socket ×1
