KING TONY 333026S 3/8 in Drive 13/16 in 12-Point Standard Socket
Hand Tools
$150.00/ 顆
$210.00
No downloads available yet
Contact JACO if you need a datasheet, certificate or another technical document.

$120.00/ 顆Was $170.00-29%
The KING TONY 333022S is an 11/16-inch imperial 12-point standard socket for matching 3/8-inch square-drive hand tools. Its standard short body is 29 mm long and weighs 46 g. This listing is for one socket, not a socket set.

| Brand | KING TONY |
|---|---|
| Manufacturer model | 333022S |
| Square drive | 3/8 inch |
| Imperial fastener size | 11/16 inch |
| Opening profile | 12-point |
| Socket form | Standard short body |
| Fastener-end outside diameter D1 | 23.8 mm |
| Drive-end outside diameter D2 | 20.0 mm |
| Diagram depth ℓ | 11.0 mm |
| Overall length L | 29 mm |
| Weight | 46 g |
| Material | Chrome vanadium alloy steel |
| Finish | Polished and chrome-plated |
| Retention design | Four ball-retaining grooves |
| Manufacturer-listed specification | ANSI/ASME B107.1 |
| Pricing unit | 顆 (one socket) |
