Name: KING TONY 237507M 1/4-inch Drive E7 External-Star Socket
Brand: KING TONY
SKU: KT-237507M
Price: 90 TWD
Availability: InStock

The KING TONY 237507M is an E7 external-star socket with a 1/4-inch square drive for external six-lobed star fasteners. It measures 24 mm overall and is made from polished, chrome-plated chrome-vanadium alloy steel. This listing is sold as one individual socket, not a socket set.

Features

E7 female six-lobed profile for matching external-star fasteners.
1/4-inch square drive with four detent grooves.
Chrome-vanadium alloy steel with a polished, chrome-plated finish.
Manufacturer specifies DIN 3120.

KING TONY 2375M-series white-background representative socket marked 4; this 237507M listing is E7, 1/4-inch drive, 24 mm, sold individually — Manufacturer-supplied KING TONY 2375M-series representative photograph: the pictured socket has a readable “4” engraving and its size markings may differ from this item; it is not an exact 237507M photograph. The item sold here is E7 with a 1/4-inch drive and 24 mm overall length, sold individually.

KING TONY 2375M-series socket section drawing with D1, D2, l and L labels; see the specification table for exact 237507M dimensions — Manufacturer 2375M-series section drawing. D1, D2, l and L refer to the specification table; the figures here come from the exact 237507M E7 row.

Specifications

Brand	KING TONY
Manufacturer model	237507M
Socket size	E7, for external six-lobed star fasteners
Square drive	1/4 inch
Working-end outside diameter D1	8.5 mm
Drive-end outside diameter D2	11.8 mm
Working-end depth l	7.0 mm
Overall length L	24 mm
Weight	11 g
Material	Chrome-vanadium alloy steel
Finish	Polished and chrome-plated
Retention design	Four detent grooves
Standard	DIN 3120
Selling unit	One individual socket

What's in the Box

KING TONY 237507M E7 external-star socket, 1/4-inch drive × 1

Features

E7 female six-lobed profile for matching external-star fasteners.
1/4-inch square drive with four detent grooves.
Chrome-vanadium alloy steel with a polished, chrome-plated finish.
Manufacturer specifies DIN 3120.

Specifications

Brand	KING TONY
Manufacturer model	237507M
Socket size	E7, for external six-lobed star fasteners
Square drive	1/4 inch
Working-end outside diameter D1	8.5 mm
Drive-end outside diameter D2	11.8 mm
Working-end depth l	7.0 mm
Overall length L	24 mm
Weight	11 g
Material	Chrome-vanadium alloy steel
Finish	Polished and chrome-plated
Retention design	Four detent grooves
Standard	DIN 3120
Selling unit	One individual socket

What's in the Box

KING TONY 237507M E7 external-star socket, 1/4-inch drive × 1
