KING TONY 233012M 1/4 in Drive 12 mm 12-Point Standard Socket
Hand Tools
$80.00/ 顆
$110.00
No downloads available yet
Contact JACO if you need a datasheet, certificate or another technical document.

$80.00/ 顆Was $110.00-27%
The KING TONY 233512M is a 12 mm metric 6-point standard socket with a 1/4 in square drive and an overall length of 24 mm. Select it for matching hexagonal nuts and bolts, and check the drive size when pairing it with a ratchet or extension. This listing is for one socket, not a socket set.


| Brand | KING TONY |
|---|---|
| Model | 233512M |
| Square drive | 1/4 in |
| Opening | Metric 6-point |
| Size across flats | 12 mm |
| Overall length L | 24 mm |
| Fastener-end outside diameter D1 | 16.8 mm |
| Drive-end outside diameter D2 | 15.5 mm |
| Opening depth l | 9 mm |
| Weight | 22 g |
| Material and finish | Chrome vanadium alloy steel; polished and chrome-plated |
| Reference standards | DIN 3124; ISO 2725-1 |
| Price unit | 顆 (one socket) |
