KING TONY 233010S 1/4-inch Drive 5/16-inch 12-Point Standard Socket
Hand Tools
$60.00/ 顆
$90.00
No downloads available yet
Contact JACO if you need a datasheet, certificate or another technical document.

$60.00/ 顆Was $90.00-33%
The KING TONY 233510S is a 5/16-inch SAE 6-point standard socket with a 1/4-inch square drive. Its overall length is 24 mm. Use it with compatible hand-driven square-drive tools on matching hexagonal fasteners; check the socket opening and the drive size separately before selecting a tool.

| Brand | KING TONY |
|---|---|
| Model | 233510S |
| Square drive | 1/4 inch |
| Socket opening | 5/16 inch (SAE) |
| Profile / form | 6-point / standard length |
| Socket-end diameter D1 | 11.4 mm |
| Drive-end diameter D2 | 11.8 mm |
| Opening depth l | 8 mm |
| Overall length L | 24 mm |
| Weight | 11 g |
| Material / finish | Chrome vanadium alloy steel / polished, chrome-plated |
| Referenced standard | ANSI/ASME B107.1 |
| Sales unit | One socket (顆) |
