KING TONY 233505S 1/4-inch Drive 5/32-inch 6-Point Standard Socket
Hand Tools
$60.00/ 顆
$90.00
No downloads available yet
Contact JACO if you need a datasheet, certificate or another technical document.

$60.00/ 顆Was $90.00-33%
The KING TONY 233509S is an imperial six-point standard hand socket with a 9/32-inch opening and a 1/4-inch square drive. It is intended for matching imperial hexagonal fasteners and compatible hand-drive tools. The 24 mm body weighs 11 g. This listing is for one socket, not a socket set.

| Brand | KING TONY |
|---|---|
| Model | 233509S |
| Square drive | 1/4 inch |
| Socket size | 9/32 inch |
| Pattern | Imperial six-point standard hand socket |
| Working-end diameter D1 | 10.3 mm |
| Drive-end diameter D2 | 11.8 mm |
| Recess depth l | 7 mm |
| Overall length L | 24 mm |
| Weight | 11 g |
| Material | Chrome vanadium alloy steel |
| Finish | Polished, chrome plated |
| Retention design | Four ball-retaining grooves |
| Standard referenced | ANSI/ASME B107.1 |
| Selling unit | One socket |
