KING TONY 233506M 6 mm 1/4-inch Drive 6-Point Standard Socket
Hand Tools
$60.00/ 顆
$90.00
No downloads available yet
Contact JACO if you need a datasheet, certificate or another technical document.

$60.00/ 顆Was $90.00-33%
The KING TONY 233006M is the 6 mm metric 12-point standard socket in the 2330M family. Its 1/4-inch square drive fits matching hand-tool drive accessories. The socket is 24 mm long. This listing is for one 6 mm socket, not a multi-size socket set.


| Brand | KING TONY |
|---|---|
| Model | 233006M |
| Family | 2330M |
| Square drive | 1/4 inch (6.35 mm) |
| Metric size | 6 mm |
| Working end | 12-point |
| Type | Standard hand socket |
| Overall length L | 24 mm |
| Working-end diameter D1 | 9.2 mm |
| Drive-end diameter D2 | 11.8 mm |
| Internal working depth l | 7 mm |
| Weight | 11 g |
| Material | Chrome vanadium alloy steel |
| Finish | Polished, chrome plated |
| Retention | Four ball-detent grooves |
| Referenced standards | DIN 3124, ISO 2725-1 |
| Selling unit | One socket |
