KING TONY 223510S 1/4" Drive 5/16" 6-Point Deep Socket
Hand Tools
$100.00/ 顆
$140.00
No downloads available yet
Contact JACO if you need a datasheet, certificate or another technical document.

$120.00/ 顆Was $170.00-29%
The KING TONY 223518S is a 9/16 in. six-point deep hand socket with a 1/4 in. square drive. Its 50 mm overall length provides a deep-body option for selecting the correct socket for the fastener and working space. This listing is for one socket, not a socket set.


| Brand | KING TONY |
|---|---|
| Manufacturer model | 223518S |
| SKU | KT-223518S |
| Type | Imperial 6-point deep hand socket |
| Square drive | 1/4 in. |
| Socket size | 9/16 in. |
| Diameter D1 | 19.6 mm |
| Diameter D2 | 19.6 mm |
| Dimension l (see section drawing) | 21 mm |
| Overall length L | 50 mm |
| Weight | 71 g |
| Material | Chrome vanadium alloy steel |
| Finish | Polished, chrome plated |
| Retention | Four ball-retention grooves |
| Manufacturer-listed standard | ANSI/ASME B107.1 |
| Selling unit | One socket (priced per 顆) |
