KING TONY 223509M 1/4-inch Drive 9 mm 6-Point Deep Socket

Brand: KING TONY
Manufacturer model number: 223509M
Order code: Y8E58CU
MOQ: 1 顆
Supply status: In Stock
Selected configuration: Standard item

$100.00/ 顆~~Was $140.00~~-29%

Payment Options: FPSFlexible PaymentBank Transfer
Buyer Protection: Genuine ProductsCompany InvoiceAfter-sales Service

Sold by

JACO自營旗艦店

自營

The KING TONY 223509M is a 9 mm metric, six-point deep socket with a 1/4-inch square drive and an overall length of 50 mm. Use it with compatible hand-operated ratchets or socket handles for 9 mm hex nuts and bolts. This listing is for one socket, not a multi-size 2235M set.

Features

Chrome vanadium alloy steel with a polished, chrome-plated finish.
Metric 9 mm six-point working end.
Four-ball retaining-groove design for compatible 1/4-inch square-drive hand tools.
Manufacturer lists DIN 3124 and ISO 2725-1 as the applicable standards.

Manufacturer 2235M-series deep metric six-point socket image marked 13; this 223509M listing is 9 mm, 1/4-inch drive, sold individually — The photograph is the manufacturer's 2235M-series representative image and is visibly marked 13, not the 9 mm size sold here. This listing is model 223509M: 9 mm, 1/4-inch drive, 50 mm overall length, sold individually. Refer to the specification table for the actual dimensions.

Manufacturer 2235M-series socket section diagram identifying D1, D2, l and L; see the 223509M specification table for the actual dimensions — The 2235M-series section diagram identifies D1, D2, l and L dimension positions. The actual 223509M values are listed in the specification table below.

Specifications

Brand	KING TONY
Model	223509M
Working end	Metric 9 mm / 6-point
Square drive	1/4 inch
Overall length L	50 mm
Hex-end depth l	15 mm
Outside diameter D1	13.0 mm
Outside diameter D2	13.0 mm
Weight	30 g
Material	Chrome vanadium alloy steel
Finish	Polished, chrome plated
Listed standards	DIN 3124; ISO 2725-1
Sales unit	One socket

What's in the Box

KING TONY 223509M 9 mm metric 6-point deep socket ×1
