KING TONY 223508S 1/4-inch Drive 1/4-inch 6-Point Deep Socket

Brand: KING TONY
Manufacturer model number: 223508S
Order code: Y8EU5CK
MOQ: 1 顆
Supply status: In Stock
Selected configuration: Standard item

$100.00/ 顆~~Was $140.00~~-29%

Payment Options: FPSFlexible PaymentBank Transfer
Buyer Protection: Genuine ProductsCompany InvoiceAfter-sales Service

Sold by

JACO自營旗艦店

自營

KING TONY 223508S is a hand-tool deep socket with a 1/4-inch square drive, a 1/4-inch imperial socket opening and a 50 mm overall length. Its six-point working end fits matching hexagonal fasteners. This listing is sold individually, not as a socket set.

Manufacturer 2235S-series representative deep socket, engraved 1/2; this 223508S listing is 1/4-inch socket size with 1/4-inch drive, sold individually — Manufacturer-supplied KING TONY 2235S-series representative image. The pictured socket is engraved 1/2 and is not an exact-size photograph of 223508S. This listing is the 1/4-inch socket opening with a 1/4-inch square drive and 50 mm overall length, sold as one individual socket.

Features

Six-point socket opening for matching 1/4-inch imperial hex fasteners.
Deep, 50 mm body with D1 of 9.5 mm and D2 of 11.8 mm for clearance comparison.
Chrome vanadium alloy steel with a polished, chrome-plated finish.
Four ball-retaining grooves at the drive end for tool retention.
Manufacturer specification references ANSI/ASME B107.1.

KING TONY 2235S-series socket cross-section drawing labelled D1, D2, lowercase l and uppercase L; exact 223508S values are in the table — Manufacturer 2235S-series dimension-location diagram. Refer to the table for the exact 223508S D1, D2, lowercase l and uppercase L values; the illustration is not a measured photograph of this size.

Specifications

Brand	KING TONY
Manufacturer model	223508S
Square drive	1/4 inch
Socket opening	1/4 inch (imperial)
Working profile	6-point
Type	Hand-tool deep socket
D1	9.5 mm
D2	11.8 mm
Lowercase l	9 mm
Overall length L	50 mm
Weight	23 g
Material	Chrome vanadium alloy steel
Finish	Polished, chrome plated
Retention	4 ball-retaining grooves
Standard	ANSI/ASME B107.1
Sales unit	One individual socket

What's in the Box

223508S 1/4-inch imperial 6-point deep socket × 1
