Name: KING TONY 223013M 1/4 in. Drive 13 mm 12-Point Deep Socket
Brand: KING TONY
SKU: KT-223013M
Price: 120 TWD
Availability: InStock

KING TONY 223013M is a metric 13 mm, 12-point deep hand socket with a 1/4-inch square drive. Its 50 mm overall length provides a deeper socket body than a standard-length socket. This listing is for one socket.

Features

Chrome vanadium alloy steel with a polished, chrome-plated finish.
Four ball-detent grooves for retention on a compatible square-drive tool.
Metric 12-point opening for matching 13 mm fasteners.
Manufactured according to DIN 3124 and ISO 2725-1.

KING TONY 2230M-series representative deep socket; pictured engraving is not this model. This listing is the 223013M, 13 mm, 1/4-inch-drive socket, sold individually. — Manufacturer’s 2230M-series representative photograph; the pictured size/model markings may differ. The actual listed model is 223013M: 13 mm, 1/4-inch drive, sold individually.

KING TONY 2230M-series sectional dimension diagram; 223013M is 13 mm, D1 and D2 17.8 mm, depth ℓ 21 mm, length L 50 mm. — Manufacturer’s 2230M-series dimension-symbol diagram, not a product photograph. The exact 223013M dimensions are listed below.

Specifications

Model	223013M
Square drive	1/4 in. (6.35 mm)
Socket size	13 mm
Profile	12-point
Overall length L	50 mm
Socket-end diameter D1	17.8 mm
Drive-end diameter D2	17.8 mm
Socket-end depth ℓ	21 mm
Weight	49 g
Material and finish	Chrome vanadium alloy steel; polished, chrome plated
Standards	DIN 3124, ISO 2725-1
Selling unit	One socket (source UOM: 顆)

Package contents

223013M 13 mm 12-point deep socket ×1.

Features

Chrome vanadium alloy steel with a polished, chrome-plated finish.
Four ball-detent grooves for retention on a compatible square-drive tool.
Metric 12-point opening for matching 13 mm fasteners.
Manufactured according to DIN 3124 and ISO 2725-1.

Specifications

Model	223013M
Square drive	1/4 in. (6.35 mm)
Socket size	13 mm
Profile	12-point
Overall length L	50 mm
Socket-end diameter D1	17.8 mm
Drive-end diameter D2	17.8 mm
Socket-end depth ℓ	21 mm
Weight	49 g
Material and finish	Chrome vanadium alloy steel; polished, chrome plated
Standards	DIN 3124, ISO 2725-1
Selling unit	One socket (source UOM: 顆)

Package contents

223013M 13 mm 12-point deep socket ×1.
